Wide-Width Thermoformable Film for Automotive Carpet Lamination and Vacuum Forming
Describe
Fuya 3000mm Wide Thermoforming Film is supplied for industrial forming and lamination projects that need a broad, stable web. The wide roll helps cover large surfaces with a clean appearance and supports vacuum forming or lamination processes where width control, surface flatness and handling stability matter.
In automotive carpet, building material and other industrial applications, the film must run smoothly, form evenly and keep the finished surface tidy after heating and shaping. A stable film helps reduce wrinkles, uneven stretching and edge problems during production.
Width, thickness, color, transparency, surface feel and structure can be customized according to the forming equipment, substrate, lamination method and performance requirements. Material selection can be adjusted for flexibility, heat resistance, bonding compatibility and processing stability.
3000mm-wide thermoforming film for automotive carpet lamination and industrial coverings. Custom structures per width and end-use application. Send your dimensions and specifications via the Send Inquiry form - response within 24 hours.
| Product Specifications | Sample Test Report - PA/PE · 7-layer · 150 μm | |||
| Material structure | PA/PE and customized multilayer structures | Test item | Measured result | Test standard / condition |
| Layer options | Customized co-extruded structures for lamination applications | Tensile strength | TD 75 / MD 72 N/15 mm | GB/T 1040.3 |
| Thickness range | 30–200 μm | Elongation at break | TD 480% / MD 465% | GB/T 1040.3 |
| Maximum width | Up to 3,500 mm | Heat-seal strength | 54 N/15 mm | QB/T 2358; 140°C; 1 s; 0.2 MPa |
| Applications | Automotive carpet lamination and industrial coverings | Peel strength | 10.5 N | GB/T 2790 |
| Features | Moisture barrier, puncture resistance, structural integrity and lamination compatibility | Coefficient of friction | μs 0.27 / μd 0.22 | GB 10006 |
| Customization | Structure, thickness, width, color and lamination performance | WVTR | 3.2 g/(m²·24 h) | GB/T 1037; 38°C / 90% RH |
| Documents | Technical data and sample test reports available on request | OTR | 22.5 cm³/(m²·24 h·0.1 MPa) | GB/T 1038 |
| RFQ information | Carpet or substrate type, lamination temperature, thickness, width, quantity and destination country | Results apply only to the tested PA/PE 7-layer, 150 μm sample. Final performance depends on the confirmed structure, thickness and test conditions. Full report available on request. | ||
Carpet lamination depends on the substrate, temperature, pressure and bond behavior rather than food-packaging barrier data. Send the carpet or foam structure, lamination temperature, target width and roll requirements for a dedicated industrial sample.
Applications
Automotive Carpet Lamination: Laminated to carpet or foam backing as a moisture barrier and forming layer for molded car floor carpets.
Vacuum-Formed Industrial Coverings: Wide rolls up to 3,000 mm cover large panels in one piece, reducing seams.
Building Materials: Used as a protective or barrier layer on panels and boards that are heat-formed or laminated.
Pics
About Factory
Packing & Delivery
FAQ
Q: 1How to order ?
A: Contact our sales, send us film dimensions, qty, and specifications details, after we checked all details we will send you formal quotation
Q: 2 What size can we provide?
A: We provide thicknesses from 25-380 microns, with a max width of up to 3500 mm,customize size available
Q: 3 when can i get them after placed an order ?
A: Normally our prepare goods time 2-3days , if customize films at least 1 week
Q: 4 Can we get sample for testing
A: Yes we can provide sample for free
Q: 5 Why Choose us?
A: We have extensive industry experience and a professional team. 24 Hours Online Service. Good service with high quality products for selling, fast delivery with careful after selling services.
