Multilayer Thermoforming Film for Meat, Seafood and Cheese Packaging
Describe
Fuya Thermoforming Film is supplied for automatic vacuum and MAP food packaging lines that need smooth forming, clear product display and dependable sealing. It helps the bottom web form evenly into the tray cavity, so the finished pack looks tidy and feels stable when handled, stacked and transported.
For meat, seafood, cheese and ready meals, the package must protect the product without hiding it. A clear surface improves shelf presentation, while the multilayer structure supports puncture resistance, sealing strength and oxygen-barrier performance when required by the application.
The film can be used as forming bottom web and matched with a suitable top film. Structure, thickness, width, transparency, color, printing and barrier level can be customized according to food type, forming depth, vacuum or MAP process, storage conditions and packaging machine.
For vacuum and MAP packaging of meat, seafood and cheese. Configurable barrier levels per shelf-life target. Food-contact certified. Share application details via the Send Inquiry form - response within 24 hours.
| Product Specifications | Sample Test Report - PA/PE · 7-layer · 150 μm | |||
| Material structure | PA/PE; PA/EVOH/PE; PE/EVOH/PE | Test item | Measured result | Test standard / condition |
| Layer options | 7-layer, 9-layer and 11-layer; standard-, medium- and high-barrier options | Tensile strength | TD 75 / MD 72 N/15 mm | GB/T 1040.3 |
| Thickness range | 30–400 μm | Elongation at break | TD 480% / MD 465% | GB/T 1040.3 |
| Maximum width | Up to 3,500 mm | Heat-seal strength | 54 N/15 mm | QB/T 2358; 140°C; 1 s; 0.2 MPa |
| Applications | Vacuum and MAP packaging for meat, seafood, cheese and ready meals | Peel strength | 10.5 N | GB/T 2790 |
| Features | Configurable barrier, deep forming, puncture resistance and stable sealing | Coefficient of friction | μs 0.27 / μd 0.22 | GB 10006 |
| Customization | Structure, thickness, width, color, printing and barrier level | WVTR | 3.2 g/(m²·24 h) | GB/T 1037; 38°C / 90% RH |
| Documents | Test reports and applicable food-contact documents available on request | OTR | 22.5 cm³/(m²·24 h·0.1 MPa) | GB/T 1038 |
| RFQ information | Packed product, packaging method, forming depth, machine type, width, quantity and destination country | Results apply only to the tested PA/PE 7-layer, 150 μm sample. Final performance depends on the confirmed structure, thickness and test conditions. Full report available on request. | ||
Vacuum and MAP packages require different barrier and sealing behavior. Tell us the product, gas mixture or vacuum process, target shelf life, top-web material and machine model; we will help narrow the structure and prepare samples for line trials.
Applications
Food Packaging (Meat and Poultry)
Used to form-fill packages for fresh, processed, and frozen meat, securely sealing them against air to keep products fresh.
Dairy Products
Ideal for packaging cheese and butter, requiring high-barrier properties to maintain freshness and prevent contamination.
Bakery and Confectionery
Provides clear, protective packaging for baked goods like bread and cakes, often offering easy-peel functionality for convenience.
Ready-to-Eat Meals
Used for forming trays and lids for convenience food, with high heat resistance suitable for varied processing methods.
Advantages
Superior Product Protection
These films offer high tensile strength, puncture resistance, and toughness, ensuring product integrity during transport and storage, even for items with sharp edges.
Extended Shelf Life (Barrier Properties)
Many flexible thermoforming films, such as those incorporating EVOH, act as high-barrier materials against oxygen, moisture, and odors. This preserves the taste, quality, and freshness of perishables like meats, cheese, and seafood.
Versatile Design & Conforming Shape
Because the films are flexible, they can be heated and formed into almost any shape, tightly conforming around products to provide a superior, high-gloss appearance that enhances retail appeal.
Cost-Effectiveness & Sustainability
They are typically lighter than rigid alternatives, resulting in lower shipping costs and reduced material usage. Many options are also recyclable, helping companies meet sustainability goals.
Compatibility with Modern Packaging Techniques
These films work seamlessly with vacuum, Modified Atmosphere Packaging (MAP), and skin packaging systems to optimize freshness.
Transparency and Display
High-quality, clear, or printed flexible films provide excellent visibility, allowing consumers to see the product's quality.
Pics
About Factory
Packing & Delivery
FAQ
Q: 1How to order ?
A: Contact our sales, send us film dimensions, qty, and specifications details, after we checked all details we will send you formal quotation
Q: 2 What size can we provide?
A: We provide thicknesses from 25-380 microns, with a max width of up to 3500 mm,customize size available
Q: 3 when can i get them after placed an order ?
A: Normally our prepare goods time 2-3days , if customize films at least 1 week
Q: 4 Can we get sample for testing
A: Yes we can provide sample for free
Q: 5 Why Choose us?
A: We have extensive industry experience and a professional team. 24 Hours Online Service. Good service with high quality products for selling, fast delivery with careful after selling services.
