Compare EVOH barrier film options for oxygen-sensitive packaging, including coextruded, thermoforming and food-focused multilayer structures.
Describe
Different products need different types of protection. Fresh meat may be affected by oxidation and color change, coffee by aroma loss, and deep-draw packs by thinning at corners after forming.
This category brings together EVOH barrier films for three common buying routes: coextruded structures, deep-draw thermoforming and application-specific food packaging. Supporting PA, PE or PP layers are selected for strength, moisture protection, processing and sealing.
Start with the page that matches your package. If the correct route is unclear, send the product, package format, storage conditions, target shelf life, sealing material and equipment. FUYA can then narrow the structure and sample options.
| Product Specifications | Sample Test Report - PA/EVOH/PE · 11-layer · 150 μm | |||
| Material structure | PA/EVOH/PE; PP/EVOH/PP; PE/EVOH/PE | Test item | Measured result | Test standard / condition |
| Layer options | 7-layer, 9-layer and 11-layer high-barrier structures | Thickness | 151 μm | Nominal 150 μm |
| Thickness range | 50–400 μm | Haze | 4.2% | GB/T 2410-2008 |
| Maximum width | Up to 3,500 mm | Tensile strength | TD 76 / MD 72 N/15 mm | GB/T 1040.3 |
| Applications | Meat, cheese, coffee, prepared food, pet food and selected medical packaging | Elongation at break | TD 490% / MD 475% | GB/T 1040.3 |
| Features | Configurable oxygen barrier, aroma retention, transparency, puncture resistance and stable sealing | Heat-seal strength | 56 N/15 mm | QB/T 2358 |
| Customization | Thickness, width, color, printing and barrier level | Peel strength | 10.5 N | GB/T 2790 |
| Documents | ISO 13485, test reports and food-contact documents available on request | Coefficient of friction | μs 0.25 / μd 0.21 | GB 10006 |
| RFQ information | Product, package format, target shelf life, storage temperature, pack atmosphere, seal substrate, equipment, roll size, quantity and destination | WVTR | 2.7 g/(m²·24 h) | GB/T 1037; 38°C / 90% RH |
| Specification values are customized by structure and application; confirm the selected specification before sampling or quotation. | OTR | 1.2 cm³/(m²·24 h·0.1 MPa) | GB/T 1038 | |
| Results apply only to the tested PA/EVOH/PE 150 μm sample. Report environment: 25°C / 50% RH · Test date: 2021-11-04 · Full report available on request. | ||||
Barrier performance should be selected from the product's oxygen sensitivity and shelf-life target, not from the EVOH name alone. Send the product, package format, storage conditions and sealing substrate so the barrier layer and supporting structure can be reviewed as one system.
Applications
Meat, Fish, Seafood, Vegetables, Fruits and Poultry Packaging
Cheese and Deli Packaging
Coffee, Tea, and Snack Packaging
Dairy Products, Soy Sauce, and other Oil-Containing Product Packaging
Pet Food Packaging
Medical Packaging
Product Advantages
- High barrier properties and puncture resistance, extending shelf life and preserving aroma of products;
- Good film transparency and appearance, good thickness tolerance, and good heat-sealing performance;
- Special multi-layer structure provides the film with excellent mechanical properties and processing adaptability;
- Boiling water resistant and stretchable.
Pics
About Factory
Packing & Delivery
Factory
FAQ
Q: 1How to order ?
A: Contact our sales, send us film dimensions, qty, and specifications details, after we checked all details we will send you formal quotation
Q: 2 What size can we provide?
A: We provide thicknesses from 25-380 microns, with a max width of up to 3500 mm,customize size available
Q: 3 when can i get them after placed an order ?
A: Normally our prepare goods time 2-3days , if customize films at least 1 week
Q: 4 Can we get sample for testing
A: Yes we can provide sample for free
Q: 5 Why Choose us?
A: We have extensive industry experience and a professional team. 24 Hours Online Service. Good service with high quality products for selling, fast delivery with careful after selling services.
